In the computer science world, Morse Code is one of those old-timey technologies that’s still cool. We’ve all watched movies about WWII where governments send telegraphs using Morse Code to transmit messages across huge distances. We’ve probably also watched Navy movies where ship commanders are sending the famous “SOS” when a ship is in trouble. This technology was ground-breaking when it was developed, and it’s still relevant today.

Since I was interested in this, I thought it would be cool to create Morse Code with a program if I could. I Googled this for a little while, and found several people used the Web Audio API to generate Morse Code with Javascript. Then I spent subsequent time reading (and coding) with both Javascript Timers and the Web Audio API playing with different methods of sending messages via light (colors) and sound.

And ultimately, since a lot of this was kinda cool, I decided to write a post on it.

The rest of this post is going to cover some cool ways to create Morse Code with Javascript. I’m going to walkthrough implementations using both the Web Audio API and Javascript’s setTimeout function.

Some History about Morse Code

Downton Abbey fans will undoubtedly remember the various telegraphs that are exchanged during the show (click here for the photo source)

Morse Code has also been widely used throughout the US Military (and in other countries) for over 100 years. Some famous war movies to showcase them include The Hunt for Red October and The Imitation Game.

I recommend checking out the Morse Code Wikipedia Page and the Telegraph Wikipedia Page to learn more.

A History of Web Audio

Web Audio Through History (click here for the source)

Now that you’ve got some background on Morse code, let’s talk about how you could use Javascript to transmit it with colors and sounds.

Sound has always been a challenge as browsers have developed. The initial web browser’s had very minimal support for sound with specific elements. When flash media was developed, it provided a cross browser solution but still required users to install software. Flash media plugins were also less than optimal.

With HTML5, the <audio> element fixed a lot of issues, but had huge limitations if you wanted to generate your own sounds from web apps. the <audio> element did not give you fine grain control over sounds and manipulation like a DJ would do.

With the advent of the Web Audio API, all of the previous challenges were resolved as it provided a framework to do (almost) any type of sound work you can think of.

Introducing the Web Audio API

OK, so lets start at the beginning…

The Web Audio API is really just a virtual way of creating a sound system. This can be considered similar to what a DJ uses when creating “mixes”.

(click here for the photo source)

The Web Audio API is really a set of “nodes” that are different parts of a virtual network. You create this network to simulate sounds and connect a source (either recorded sound or generated) to a destination (speakers). The following is a great overall diagram I copied from the MDN pages here:

The overall Audio Network that is created with the Web Audio API is called an Audio Graph. The Web Audio API calls this Audio Graph the AudioContext, which is basically where audio can run in your current browser session. Every browser has an AudioContext and you’ll need to know how to reference it to be able to use the Web Audio API.

In addition to just sound, you can also create visualizations of sound with the Web Audio API’s Analyser Node.

If all of this seems a little hard to understand, I recommend you watch the following video that walks through the basics.

Morse Sound

You can play with a running version of the app here. You can also view the source code for the app on GitHub here.

Since the app follows the basic structure of Angular, I’m not going to do the standard “ng new” and app setup. I’m just going to walkthrough how the main component works with the Web APIs. Please checkout the source code to see how the app was created at the GitHub link I provided above.

The app itself just takes in text, plays the text as Morse Code and also outputs the translated result as in the following screenshot.

So lets walkthrough setting this up…

First I should note that the Web Audio API is supported by most modern browsers today, but there may be small differences for specific browser implementation. The code that I’m covering here is made for Google Chrome.

As a security measure, Chrome won’t play audio without a gesture happening first. This makes sense since you don’t want apps to be able to tap into your computers audio without your consent etc. So in order to do this, the main webform of my App creates the Audio Context with the onSubmit which is tied to the main form that takes in input. Here’s the code:

The createContext method here creates the Audio Graph that we’ve been talking about. First, we create an instance of the AudioContext, oscillator, and gain node with the following:

this.audioContext = new AudioContext();
this.oscillator = this.audioContext.createOscillator();
this.gain = this.audioContext.createGain();

Next, we set the value for the gain node to be “0” to simulate it as being off (makes it not play a sound). Then we set the frequency (pitch) of the oscillator, connect the oscillator to the gain node, and connect the gain node to the speakers (audio destination) with the following:

this.gain.gain.value = 0;
this.oscillator.frequency.value = 750;
this.oscillator.connect(this.gain);
this.gain.connect(this.audioContext.destination);

Finally, we set the rate at which the sounds will play and start the oscillator node. This is important because it becomes the value that we set to “schedule” sounds with the network.

this.dot = 1.2 / this.rate;
this.oscillator.start(0);

The resulting Audio Graph should look somewhat like the following diagram:

In the graph here, all of the nodes exist within an AudioContext. The three Nodes that are listed here are just part of the Audio Graph. The oscillator connects to the gain which then creates output that is sent to the Speakers (Audio Destination).

With the Audio Graph setup, we next need to go about the business of creating the sounds. Here we are going to “schedule” sounds by simulating turning the gain node “on” and “off”. We do this by literally setting the gain value to “0” or “1” at specific intervals in time. Think of this like literally turning volume on and off on a speaker. We do this with the following:

generateMorse(time: any, phrase: string) {
phrase = phrase.toUpperCase();
this.morseDisplay = [];
for (const p of phrase) {
if (p === ' ') {
time += 3 * this.dot;
} else if (this.MORSE[p] !== undefined) {
time = this.createSound(time, this.MORSE[p]);
time += 2 * this.dot;
}

const morseOuput = new MorseOutput();
morseOuput.morseText = p;
morseOuput.morseValue = this.MORSE[p];
this.morseDisplay.push(morseOuput);
}

return time;
}

The generateMorse method uses the AudioContext’s time with audioContext.currentTime property. The AudioContext has an internal clock that is continually counting once it is created. We’re going to use the audioContext.setValueAtTime method to “schedule” audio sounds using this clock. This is why the time is passed in as a parameter to the generateMorse method.

The array MORSE is just a set of key value pairs that correlate a character entered with a Morse Code value.

Also notice the use of the dot value to schedule time. This determines the frequency (pace) that the “dots” and “dashes” will be played by the program.

With the generateMorse method, the for loop walks through the phrase passed to it and then calls the createSound method. This method is where all the magic happens.

createSound(time: any, char: string) {
for (const c of char) {
switch (c) {
case '.':
this.gain.gain.setValueAtTime(1.0, time);
time += this.dot;
this.gain.gain.setValueAtTime(0.0, time);
break;
case '-':
this.gain.gain.setValueAtTime(1.0, time);
time += 3 * this.dot;
this.gain.gain.setValueAtTime(0.0, time);
break;
}
time += this.dot;
}

return time;
}

This method calls the gain node setValueAtTime method which “schedules” the sounds to be played within the created Audio Graph. The return value is important because it forces the Javascript Event Loop to use the sound generation as an operation on the stack. If you don’t include the return then the Javascript scope will miss the timing, and you won’t hear any sound.

Bringing it all together, the final product looks like this:

Checkout the running version of the app, or do a git clone and play with the code yourself.

Morse Light

A working version of this app is available here. You can also checkout the source code on GitHub here.

Here’s a screenshot of the App in action:

Just like with the sound App, I’m not going to go through the basics of creating the initial structure with the Angular CLI. I’m just going to focus on the main application logic here and recommend you review the project in GitHub for more on how the actual project is structured etc.

For the basic light presentation, I make use of async/await and the Javascript event loop to simulate the light being “on” and “off”. The app basically takes in a phrase as input, then makes timed calls to a method that returns a Promise. Since I’m using async/await, the main Javascript event loop is forced to wait until that Promise is resolved with the provided time. If you’re unfamiliar with async/await I recommend looking at my post here.

The app does most of the work with a transmit method and a flashlight method.

First, the transmit method is what is called by the “submit” button from the main input form. This method uses the async/await calls as I originally explained to control timing of the “on” and “off” light sequences.

async transmit() {
// time = 1200 / words per minute
// 20 words per minute
// follows a 3 to 1 ratio
// 60 milliseconds for one dot
// 180 milliseconds for a dash
// multiplied by factor of 4 to slow it down here
const dot = 60 * 4;
const dash = 180 * 4;

this.showMorse = '';
const messageUpper = this.message.toUpperCase();
for (const char of messageUpper) {
this.showMorse = this.showMorse + '(' + char + ') ';
const morseValue = this.morseTranslation[char];
for (const morse of morseValue) {
this.showMorse = this.showMorse + ' ' + morse;
if (morse === '.') {
// dot
await this.flashlight('yellow', dot);
// show white light to show when flash is finished
await this.flashlight('white', 60);
} else {
// dash at 3 X 60 or 180
await this.flashlight('yellow', dash);
// show white light to show when flash is finished
await this.flashlight('white', 60);
}
}
}
}

As you can see in this code, the async method calls flashlight. The call has an await which blocks the main event loop, forcing the program to wait before changing the color of the light. Based on the color value that is passed in, the call to flashlight also controls the color. So yellow simulates the light being on, and white simulates the light being off. If you pass this in with a string of Morse Code in the form of dots=”.” and dashes=”-“, then you can walkthrough that line and simulate the corresponding on and off values.

flashlight(color: String, time: any): Promise<any> {
return new Promise(resolve => {
setTimeout(function() {
// this.drawLight(color);
const c: any = document.getElementById('flashlight');
const ctx = c.getContext('2d');
ctx.beginPath();
ctx.arc(c.width / 2, c.height - 50, 50, 0, 2 * Math.PI);
ctx.fillStyle = color;
ctx.fill();
ctx.stroke();
resolve(true);
}, time);
});
}

The flashlight method just colors the canvas element for a specified amount of time. The real magic is where the async/await blocks the main thread forcing a wait before the draw/redraw of the canvas will change the lights color.

Putting it all together the Morse Light component looks like the following:

Wrapping Up
